CENTRASOG CVS 2.0

CENTRAL HIGH-VACUUM SYSTEM FOR INDUSTRY AND WORKSHOPS

CENTRASOG CVS 2.0

High-performance dust extraction system for up to 15 suction points.

The CENTRASOG CVS brings a side channel blower, filter unit, and control system in one housing to form a compact unit with low space requirement. The installation is available in three power stages with a maximum air volume flow of 700 to 1950 ccs per hour and a maximum vacuum pressure of 19,000 to 13,000 Pascals. Depending on the version, up to 15 suction points can be operated at the same time. The 2-stage filter system, comprising cyclonic pre-separator and filter cartridge offers effective filtration.

Gallery CENTRASOG CVS 2.0

Application CENTRASOG CVS 2.0

  • Plastic dusts

  • Metal dusts

  • Dust and shavings

Stationary setup

Fixed extraction systems which can be connected next to processing machines.

Jet-Pulse filter cleaning

Jet-Pulse filter cleaning cleans the filter cartridges individually automatically during and after suction.

  • Low operating costs due to cleanable permanent filter

  • Small space requirement due to compact design

  • Low operating costs due to cleanable permanent filter

  • High-performance side channel blower – for maximum suction performance

  • Completely pre-assembled and ready to use right away

  • Two-stage filter system with integrated cyclone pre-separator and filter cart of dust class M

Downloads & data CENTRASOG CVS 2.0

CENTRASOG CVS 2.0 8 12 15
Max. air volume flow
m³/h
700 1,000 1,950
Intake diameter
m³/h
160 160 160
Max. negative pressure
Pa
19,000 18,000 13,000
Intake voltage
V
400 400 400
Drive power
kW
8,5 12.5 15.0
Max. number of suction points
Ø 36/50 mm
6/3 10/6 15/9
Filter surface
16.0 16.0 16.0
Dust collection container
l
200 200 200
Dimensions (L/B/H)
mm
2.170 x 1,078 x 2,433 2,170 x 1,078 x 2,433 2,170 x 1,078 x 2,433
Weight
kg
840 900 950
Sound emission
dB(A)
76 78 74
CENTRASOG 8 12 15
Standard design 87500 87600 87700

Contact

WE ARE HAPPY TO PROVIDE A PERSONAL CONSULTATION

We can adapt our exhaust installations to your needs. Tailor-made, modular and individual. Ask us!

Do you have any questions about our products or services? We are happy to help!
How can we reach you?
How can we help you further?

Accessories

Extraction hoses

Conveyor connection for solid, liquid and gaseous media. Flexible, vibration-absorbent and noise-damping.

Vacuum cleaner accessories

Flexible uses for a range of applications.

Dust collection box

Tough plastic sacks for collecting gathered dust for low-dust disposal. Multi-use.

Steel pipe

For connecting multiple suction points to a central high-vacuum extraction system.
