EUROSOG-I-D

POWERFUL INDUSTRIAL VACUUM CLEANER FOR DRY DUST

EUROSOG-I-D

Industrial vacuum cleaner in A/C version for uninterrupted operation in workshops.

The EUROSOG-I-D is a high-performance industrial vacuum cleaner for coarse, dry, fine and granulated dusts. The AC version is especially suited for uninterrupted operation when cleaning in workshops. It is easy to move thanks to its smooth-turning castors. It comes fitted with a spacious dust collection container (capacity: 80 litres). The patented tilt-back mechanism allows dust to be disposed of effortlessly.

Gallery EUROSOG-I-D

Application EUROSOG-I-D

  • Removal of coarse and fine dusts when cleaning

  • For cleaning processing machines

  • Can be used in many industries (e.g. wood and metal industry)

  • Sawing, cutting, separating
  • Grinding, polishing
  • Machining, milling
  • Cleaning
  • Drilling
  • Turning

  • Cotton wool fibres

  • Wood shavings

  • Wood dusts

  • Metal dusts

  • Mineral dusts

  • Paper dusts

  • Tobacco fibres

Dust class M

Suitable for the extraction of harmful dusts.

Dust class H

Suitable for the extraction of all harmful/carcinogenic dusts.

ATEX-Zone 22

For extracting dry, combustible, non-conductive dusts in Zone 22.

ATEX-COMPLIANT

For use in areas subject to risk of explosion.

TÜV SÜD GS

Meets the requirements of the German Product Safety Act  § 20 – 22 ProdSG.

Mobile set-up

Easy and flexible to use makes it ideal for frequently-changing use locations.

Manual brush cleaning

Cartridge filters are fitted with brushes to remove dry and granulated dusts from the filter.

  • Low-noise, high-performance vacuum cleaner for dry dusts

  • Low operating costs due to cleanable permanent filter

  • Tilt-back filter housing for easy dust disposal

  • Small space requirement due to compact design

  • High mobility by smooth-turning castors

  • For defined uninterrupted operation (A/C vacuum cleaner)

  • Manual brush cleaning

  • Cleanable long life filter cartridges available for dust class M and H

  • Test certificates M, H and B22* available

  • Optional as ATEX model


*Suitable for extracting dry, combustible dusts in Zone 22.

Downloads & data EUROSOG-I-D

EUROSOG I-D
Max. air volume flow
m³/h
360
Intake diameter
mm
50
Max. negative pressure
Pa
19,500
Intake voltage
V
400
Drive power
kW
2.2
Filter surface
5
Dust collection sack
l
80
Dimensions (L/B/H)
mm
1,030 x 670 x 1,240
Weight
kg
81
Sound emission
dB(A)
77
EUROSOG I-D
EUROSOG I-D/N (standard device) 81198
EUROSOG I-D/M with TÜV test certificate dust class M 81399
EUROSOG I-D/H with TÜV test certificate dust class H 81299
EUROSOG I-D/M/B22 with TÜV test certificate dust class M and additional test B22* 81397
EUROSOG I-D/H/B22 with TÜV test certificate dust class H and additional test B22* 81297
EUROSOG I-D ATEX design 81200

* suitable for extraction of dry, combustible dusts in Zone 22

Contact EUROSOG-I-D

WE ARE HAPPY TO PROVIDE A PERSONAL CONSULTATION

We can adapt our exhaust installations to your needs. Tailor-made, modular and individual. Ask us!

Do you have any questions about our products or services? We are happy to help!
How can we reach you?
How can we help you further?

Accessories EUROSOG-I-D

Vacuum cleaner accessories

Flexible uses for a range of applications.

Plastic filling bags

Tough plastic sacks for collecting gathered dust for low-dust disposal. Multi-use.
