DUSTOMAT S

MOBILE DUST EXTRACTOR FOR EXTRACTION OF STICKY, LONG-FIBRE DUSTS

DUSTOMAT S

Special dust-extractor for textile-, flock- and packaging industry.

DUSTOMAT S mobile dust extractors specialise in the extraction of sticky and long-fibre dusts in the textile and flocking industry. Depending on the application, extraction can be done from multiple points. This custom dust extractor also finds effective use in the packaging industry: The DUSTOMAT S is connected to the packaging machine ensuring clean extraction of dust arising during filling processes.

Gallery DUSTOMAT S

Application DUSTOMAT S

  • Custom dust extractors for sticky and long-fibrered dusts

  • Textile and flocking industry

  • Machining, milling
  • Refilling, empyting, mixing

  • Flocking dust
  • Foil tinsel
  • Sticky dust
  • Textile fibres
  • Cotton fibres

Mobile set-up

Easy and flexible to use makes it ideal for frequently-changing use locations.

  • Compact design with high suction performance

  • Easy-to-replace paper filter bag to filter out coarse dirt

  • Cotton filter bag with paper filter bag

  • Negative pressure display

Downloads & data DUSTOMAT S

DUSTOMAT 100-S 120-S 140-S 160-S
Max. air volume flow
m³/h
720 1,060 1,330 1,850
Intake diameter
mm
100 125 140 160
Max. negative pressure
Pa
2,800 3,250 3,800 4,600
Intake voltage
V
230/400 400 400 400
Drive power
kW
1.3/1.1* 2.2 3.0 3.0
Filter surface
0.75 1 1 1
Dust collection container
l
100 200 200 200
Dimensions (L/B/H)
mm
1,075 x 530 x 1,075 1,653 x 782 x 1,353 1,653 x 782 x 1,353 1,653 x 782 x 1,373
Weight
kg
70 190 200 200
Sound emission
dB(A)
71 68 69 73

* 400 V model

DUSTOMAT 100-S 120-S 140-S 160-S
Model (230 V) 09500 - - -
Model (400 V) 09497 09502 09504 09506

Contact DUSTOMAT S

WE ARE HAPPY TO PROVIDE A PERSONAL CONSULTATION

We can adapt our exhaust installations to your needs. Tailor-made, modular and individual. Ask us!

Do you have any questions about our products or services? We are happy to help!
How can we reach you?
How can we help you further?

Accessories DUSTOMAT S

Protective walls

Flexible protection walls for a safe working environment in the welding shop

Extraction arms

For capturing welding- and soldering fume, gases, vapour and dusts. Connection to extraction system or fan possible.

Extraction hoses

Conveyor connection for solid, liquid and gaseous media. Flexible, vibration-absorbent and noise-damping.

Pre-separator

For pre-separation of dry, granulated dusts, shavings and sparks. Increases the service life of the main filter of the extraction installation.

Paper bag

Disposable bags for collecting gathered dust for low-dust disposal.
