OM SERIES

Powerful mini dust collectors for low volumes of dust

OM SERIES

Dust extractors are fitted with cleanable bag filters.

OM series mini dust collectors offer multiple possible applications in dust-generating machines. They are used for almost all types of dust and feature powerful suction capacity and low operating noise. For occasional use, they are suitable for uninterrupted operation and not overly-large volumes of dust. These devices are often used in the electronics industry, surface technology and metalworking firms.

Gallery OM series

Application OM series

  • For extraction of low volumes of dust

  • In applications such as sawing, milling, grinding, etc.

  • For direct extraction in processing machines

  • Sawing, cutting, separating

  • Grinding, polishing

  • Machining, milling

  • Metal dust

  • Metal shavings

  • Jewellery dust

Stationary setup

Fixed extraction systems which can be connected next to processing machines.

Manual bag filter cleaning

Pressing the hand lever puts the bag filter into vibration via a built-in eccentric screw and the dirt falls away.

  • Suitable for almost all types of dust

  • Flexible uses

  • Low operating costs due to cleanable bag filters

  • Small space requirement due to compact design

  • Cleanable durable dust collection bag

  • Large dust collection drawer

  • Filter material for fine dusts, tested to dust class M

  • Motor in A/C or three-phase A.C. current

  • Custom paint finishes

  • Water pre-separator

  • Mobile frame with four castors

  • Sound dampening muffler

Downloads & data OM series

OM 8 10 12
Max. air volume flow
m³/h
500 600 800
Intake diameter
m³/h
80 100 150
Height of suction socket
m³/h
300 300 300
Max. negative pressure
Pa
1,600 1,500 1,800
Intake voltage
V
400 400 400
Drive power
kW
0.55 0.55 1.10
Dimensions (L/B/H)
mm
550 x 550 x 1,120 550 x 550 x 1,120 550 x 550 x 1,120
Overall depth
V
670 670 670
Weight
kg
65 65 70
Sound emission
dB(A)
65 66 72
OM 8 10 12
Standard design 21081 21101 21122
