COMBICYCLONE

TWO-LEVEL COMBINATION MADE OF CYCLONIC PRE-SEPARATORS AND CARTRIDGE FILTERS

COMBICYCLONE

The cyclone filter technology is used for the extraction of mixtures consisting of coarse-grained materials and fine dust.

The Combicyclone is a two-stage combination of cyclonic pre-separator and cartridge filter. The cyclone effect first filters out heavy components from the suction air. In the second filter stage, the cartridge filter made of IFA-tested material guarantees high filtration efficiency. The cartridge filter is split into separately cleaned segments inside. The revamped cartridge filter provide constant suction output.

Application COMBICYCLONE

  • For coarse-grained material and fine dust

  • Internal car cleaning

  • Pellet delivery

  • Tobacco industry

  • Paper industry

  • Metal industry

  • Plastic industry

  • Sawing, cutting, separating

  • Welding, soldering

  • Grinding, polishing

  • Machining, milling

  • Refilling, filling, mixing

  • Direct extraction on manual working machines

  • Metal shavings

  • Plastic dusts

  • Plastic savings

  • Cotton dusts

  • Paper dusts

Mobile set-up

Easy and flexible to use makes it ideal for frequently-changing use locations.

Stationary setup

Central extraction systems are able to carry out extraction on multiple machines in parallel from its location via a pipe system.

Jet-Pulse filter cleaning

Jet-Pulse filter cleaning cleans the filter cartridges individually automatically during and after suction.

  • For separating mixtures made of coarse and fine dust

  • Simple handling of collection container

  • Automatic cleaning of filter cartridge using revamped cleaning system

  • Compact construction makes it available for use in constrained spaces too

  • Basic, quick filter replacement

  • Long filter lives

  • Auto-cleaning filter cartridge

  • Compact construction

  • Ergonomically optimized lifting system for 200L capacity collection container

Downloads & data COMBICYCLONE

COMBICYCLONE FZ-1504
Intake voltage
V
230
Max.air volume
m³/h
2,500
Nominal current
A
0.15
Nominal frequency
Hz
50
Backup fuse
A
16
Connection piece
mm
160
Compressed air requirement
l/min
at 6 bar 52
Filter elements
pieces
1
Filter surface
16
Dust collection container
l
200
Dimensions (L/B/H)
mm
942 x 652 x 2,400
Weight
kg
350
COMBICYCLONE FZ-1504
Standard design 75002500
